Follow the energy, not just the electricity meter
The missing input in the apparent paradox
Suppose a heating system delivers three kilowatt-hours of heat while consuming one kilowatt-hour of electricity. If electricity were its only energy input, something would be missing from the account. In a heat pump, the other input is thermal energy collected from outside the heated space.
In an idealized example, two kilowatt-hours arrive from the surroundings and one kilowatt-hour enters as electrical work. Together they account for three kilowatt-hours delivered indoors. These invented numbers illustrate an energy balance; they are not a performance claim for a particular product.
The International Energy Agency’s explanation of heat pumps describes systems that collect heat from air, the ground, water or waste-heat sources. The useful question is where the delivered heat came from, rather than whether the electricity meter alone measured every input.
Why the refrigerant circulates through different conditions
A common heat pump uses a circulating refrigerant and a compressor. The refrigerant encounters different pressures and temperatures around the circuit. Heat exchangers allow energy to pass between that fluid and the source or destination.
For a conventional vapour-compression system in heating mode, the main stages are:
- Evaporation: refrigerant at low pressure absorbs heat at the source-side exchanger and evaporates.
- Compression: electrical work drives a compressor, raising the vapour’s pressure and temperature.
- Condensation: hot refrigerant releases heat through the indoor exchanger and condenses.
- Expansion: a pressure-reducing device prepares the refrigerant to absorb heat again on the low-pressure side.
The names describe the refrigerant’s role at each exchanger, not an unchanging geographical location. In equipment designed to reverse its operation, the indoor and outdoor exchangers exchange their heating and cooling roles.
Natural Resources Canada’s archived Heating and Cooling With a Heat Pump explains the cycle and terminology. It is useful for fundamentals; its older product ratings, prices and buying information should not be treated as current guidance.
What COP measures
The heating coefficient of performance, or COP, compares useful heating output with electrical input. Both sides must use compatible units and refer to the same operating conditions.
Heating COP = useful heat delivered ÷ electricity consumed.
In the illustrative three-kilowatt-hour example, COP is 3 ÷ 1 = 3. The ratio has no unit because kilowatt-hours cancel. It does not mean that electricity has been converted into more energy than existed beforehand.
The ENERGY STAR heat-pump criteria distinguish COP at specified operating conditions from seasonal heating and cooling ratings. A value measured at one temperature cannot describe every hour of a winter.
Put the measurement boundary on the page
A ratio is only as useful as its definition. Consider a hypothetical test in which a compressor consumes 1 kWh and the indoor side receives 3 kWh. Reporting a compressor-only COP of 3 is straightforward.
Now suppose fans, controls and other equipment consume another 0.2 kWh during that interval, while the measured useful output remains 3 kWh. A broader calculation gives 3 ÷ 1.2 = 2.5. Neither arithmetic result is difficult; the important difference is what was counted.
This is why an article, report or sales claim should identify the system boundary. Readers need to know whether a figure includes auxiliary equipment and backup heat, and whether it represents a laboratory point, a field measurement or a seasonal calculation. Comparing two unlabeled numbers can conceal a difference in definitions.
Also distinguish power from energy. A kilowatt measures a rate. A kilowatt-hour measures an amount accumulated over time. A system delivering 3 kW continuously for two hours supplies 6 kWh of heat.
Efficiency and heating capacity answer different questions
Capacity describes how quickly a system can supply heat. COP describes the relationship between output and electrical input. Knowing one does not determine the other.
Imagine System A delivering 4 kW of heat at COP 4 and System B delivering 8 kW at COP 3, each under a stated test condition. System A needs 1 kW of electrical input; System B needs about 2.67 kW. The first has the higher ratio, while the second supplies heat faster.
These are teaching examples, not competing products. Their purpose is to show why a high efficiency figure does not establish whether equipment can meet a building’s heat demand. That requires a capacity assessment under relevant conditions.
Why installation and the rest of the system matter
A heat pump works as part of a building system. Airflow, refrigerant charge, equipment sizing and distribution affect the result an occupant experiences. An equipment label cannot by itself describe all those installation conditions.
The U.S. Department of Energy’s residential air-source heat-pump acquisition guidance identifies oversizing, improper charging and leaky ducts as causes of efficiency loss and discomfort. Its advice to assess installation quality helps explain why field operation can differ from an isolated equipment rating.
That does not make laboratory measurements useless. It means a fair comparison separates the equipment’s tested behavior from the performance of an entire installed system. Both forms of evidence have a role, but they answer different questions.
What an energy claim does not tell you
COP alone is not a utility bill. A financial comparison also needs energy prices, the heating demand, the system’s changing operating conditions and the alternative being compared. Those inputs are outside the ratio itself.
For example, if two hypothetical systems each deliver 9 kWh of useful heat, one at COP 3 and the other at COP 2, their electrical consumption is 3 kWh and 4.5 kWh respectively. That establishes a difference in electricity use for the assumed interval. It does not establish installation cost, annual savings or a payback date.
Emissions comparisons need another boundary: the sources of the electricity and any other fuel. A statement about energy transfer should not silently become a universal statement about cost or carbon emissions.
Questions worth asking of a performance figure
- Is it heating output, cooling output, capacity or an efficiency ratio?
- What source and delivery temperatures apply?
- Which electrical loads are included?
- Does the result describe one condition or a season?
- Is it a measured result, a rating or an illustrative example?
A clear answer to those questions makes the central claim easier to evaluate: a heat pump can deliver more heat than its electrical input because the surroundings supply additional energy.
Related explanations
The cooling version of the same broad idea appears in how refrigerators keep food cold. For the role of experiments and measurements in testing an explanation, read how scientific discovery works.
